Piko 52766 diesel locomotive 132 203-1, DR, Ep. IV (incl. sound)

Piko 52766 Diesel Locomotive 132 203-1, DR, Ep. IV - Powerful Diesel Locomotive with Sound

The Piko 52766 German State Railroad diesel loc omotive 132 203-1 impresses with its prototypical design and outstanding technical equipment. The locomotive from Era IV, painted in a striking purple red, impresses with the finest paintwork and printing as well as many intricate details. Free-standing handrails and the typical design of Era IV emphasize the authentic look of this model. The sturdy die-cast zinc frame ensures durability, while the powerful five-pole motor with two flywheels provides excellent running characteristics.

Excellent running characteristics and technological highlights

The Piko BR 132 is equipped with two traction tires that are positioned diagonally on the inner axles of the two bogies. This ensures excellent tractive power, even in demanding driving situations. The LED lighting is also a highlight, and both the tail light and the driver's cab lighting can be switched separately, providing additional realism.

Digital control and sound functions

Equipped with a factory-fitted PIKO sound decoder, the locomotive offers a wide range of digital control options. The decoder supports various data formats such as DCC with RailComPlus®, Motorola®, Selectrix® and M4. Up to 29 functions can be controlled digitally, including typical locomotive sounds such as the engine noise, signal horns, brake squeal and many more. In analog operation, at least the engine noise is also available.

High level of detail and robustness

The model has free-standing grab rails, which increase the level of detail even further. The die-cast zinc frame gives the model additional stability and durability, making it ideal for long-term use on your model railway layout. The powerful motor and high-quality workmanship ensure smooth operation, even on tight radii.

Perfect for Era IV layouts

With a length over buffers of 239 mm, the Piko 52766 is ideal for Era IV model railroad layouts. The minimum radius of 358 mm also makes it suitable for compact layouts, and the excellent attention to detail, combined with the comprehensive digital functions, makes this locomotive a perfect choice for model railroaders and collectors.

Features:

• Era: IV
• Track size: H0
• Power system: Direct current (DC)
• Coupler pocket according to NEM with close coupler link
• 5-pole motor with two flywheels
• 2 traction tires
• LED lighting
• PIKO sound decoder installed ex works
• Data formats: DCC with RailComPlus®, Motorola®, Selectrix® and M4
• Typical locomotive sounds such as engine noise, signal horns, brake squeal and more
• Engine noise also possible in analog operation
• Minimum radius: 358 mm
• Length over buffers: 239 mm

Specs:

• Gauge: H0
• Rail Company: DR
• Era: IV
• Color: Red
• Electricity System: DC
• Digital: Yes
• sound: Yes
• News: 2017
• Type: Diesel loco

Instruction manual / Safety instructions:

• Manual (5.12 MB)

Further links:

• Print View

CAUTION: Not suitable for children under 3 years. Danger of swallowing! Age recommendation from 14 years.
