Schönwitz 51382 Schrumpfschlauch 3,2 mm auf 1,6 mm, 1 Meter (schwarz)
Delivery time: 3 ‐ 10 business days (Germany)
Check availability in store:
- Store Oschatz: currently unavailable
Share with friends:
Schönwitz 51382 Schrumpfschlauch 3,2 mm auf 1,6 mm, 1 Meter (schwarz) Product Details
The Schönwitz 51382 heat-shrink tubing is a flexible, black heat-shrink tubing with a diameter of 3.2 mm that reduces to 1.6 mm. It is 1 meter long and provides reliable protection and insulation for cables and connections. Thanks to its 2:1 shrink ratio, it fits snugly and protects against mechanical stress and environmental influences. The heat-shrink tubing is easy to process with a hot air gun and is ideal for use in electrical and electronic applications.
The heat-shrink tubing is intended for professional use due to its excellent chemical, mechanical and electrical properties. It guarantees perfect electrical insulation and offers protection against corrosion and mechanical stress.
Supplied with 1 meter of heat-shrink tubing, pre-cut into 10 pieces of 10 cm each.
Features:
- Material: radiation cross-linked polyolefin
- Color: black
- Diameter before shrinking: 3.2 mm
- Diameter after shrinking: 1.6 mm
- Shrink ratio: 2:1
- Wall thickness after shrinkage: 0.5 mm
- Shrink temperature: '110 °C
- Longitudinal shrinkage: max. 10 %
- Operating temperature: -55 °C to +135 °C
- Tensile strength: 15.0 MPa min (ISO 37)
- Flammability: self-extinguishing
- Dielectric strength: =24 kV / mm
- Tested according to: UL224, CSA 400-U-9
- High resistance to: acids, alkalis, cleaning fluids, fuels, oils, salt water, fungal growth and rotting
