Schönwitz 51385 Schrumpfschlauch 9,5 mm auf 4,8 mm, 1 Meter (schwarz)
Delivery time: 1 ‐ 2 business days (Germany)
Check availability in store:
- Store Oschatz: can be picked up immediately
Share with friends:
Schönwitz 51385 Schrumpfschlauch 9,5 mm auf 4,8 mm, 1 Meter (schwarz) Product Details
The Schönwitz 51385 heat shrink tubing has a diameter of 9.5 mm before shrinking and reduces to 4.8 mm after shrinking. With a length of 1 meter and available in black, this heat shrink tubing is ideal for insulating and protecting larger cables and wires. When heated, the tubing shrinks to the desired size and provides a secure, firm connection. It is ideal for applications where larger cables or multiple wires need to be insulated and protected, such as in model making, electronics or other technical areas.
The heat-shrink tubing is intended for professional use due to its excellent chemical, mechanical and electrical properties. It guarantees perfect electrical insulation and offers protection against corrosion and mechanical stress.
Supplied with 1 meter of shrink tubing, pre-cut into 10 pieces of 10 cm each.
Features:
- Material: radiation cross-linked polyolefin
- Color: black
- Diameter before shrinking: 9.5 mm
- Diameter after shrinking: 4.8 mm
- Shrink ratio: 2:1
- Wall thickness after shrinking: 0.6 mm
- Shrink temperature: '110 °C
- Longitudinal shrinkage: max. 10 %
- Application temperature: -55 °C to +135 °C
- Tensile strength: 15.0 MPa min (ISO 37)
- Flammability: self-extinguishing
- Dielectric strength: =24 kV / mm
- Tested according to: UL224, CSA 400-U-9
- High resistance to: acids, alkalis, cleaning fluids, fuels, oils, salt water, fungal growth and rotting
