Piko 55033 RD 4000+ Schaltdecoder für elektrische Verbraucher

PIKO 55033 RD 4000+ Switching decoder for electrical consumers

The PIKO 55033 RD 4000+ is a versatile switching decoder for controlling electrical consumers such as lamps, light signals or motors. With the latest technology and high compatibility, it replaces the proven article 55031 and offers even more flexibility in digital system control.

Versatile control via two independent addresses

The decoder works with DCC (1-2048) and Motorola® (1-320) and can be set up via push-button or CV programming. The two switching outputs can be addressed independently of each other, which enables a wide range of application scenarios - ideal for use in complex system structures.

Modern technology in accordance with RC standard 213

The RD 4000+ complies with RC standard 213 and has two potential-free changeover contacts that can be used to switch up to four loads with external voltage. Each contact can be loaded with up to 1 ampere and thus also allows the operation of current-intensive loads.

Flexible programming for maximum control

CV programming can be carried out either via the programming track output of the central unit or via the main track programming for accessory decoders. This means that the RD 4000+ can be used flexibly and can be quickly adapted to individual requirements.

Features:

• Replaces article 55031
• RC standard 213 compliant
• 2 potential-free changeover contacts
• Maximum current load per contact: 1 A
• Protocols: DCC (1-2048), Motorola® (1-320)
• Address assignment via push-button or CV programming
• Control via two independent addresses
• Control of external voltages for up to 4 consumers
• CV programming via programming track or main track
• Switching decoder for electrical loads such as light signals, lamps and motors

Specs:

• Gauge: All
• Type: Decoder
